• Mico Excavator
Mico Excavator

The main features of our tailless excavators are compact structure, short counterweight, and a radius of gyration within the walking device. It is especially suitable for landscaping, municipal engineering and other narrow working areas.

Details

The main features of our tailless excavators are compact structure, short counterweight, and a radius of gyration within the walking device. It is especially suitable for landscaping, municipal engineering and other narrow working areas.


Suitable Working Environment

1.Agriculture: digging ditches, fertilizing, planting trees, weeding, dredging, clearing, digging medicinal herbs, forestry planting, farmland improvement, etc.

2. Ditching: ditching cable trench, artesian ditch, sewage pipeline, natural gas pipeline, drainage ditch, etc

3. Crushing demolition: indoor wall demolition, ground crushing, basement demolition, floor reconstruction, etc







1. We will arrange technicians go abroad to install or maintenance the machine if necessary.

2. Within 2 Years warranty period and the machine parts damage under normal using condition, we will offer free new ones for replacement.

3. After the expiry of warranty, we can renewal of the contract, which canenjoy the same service as that during the warranty period.


AZ08 Mini Tailless Excavator


Brand Aizhou
Modle AZ08
Operating Weight 800kg
Digging bucket capacity 0.02cbm/100kg
Bucket width 340mm
Overall dimension( LxWxH) 2770x896x1490 mm
Rated power 8.6kw/3600r/min /
OPERATING RANGE
Max. Digging depth 1650 mm
Max. Digging height 2610 mm
Max. Dumping height 1850 mm
Max. Digging radius on ground 2890 mm
Min. Rotation radius 1330 mm
Max. Upgrade height of bulldozer blade 345 mm
Max. Digging depth of bulldozer blade 255 mm



AZ10 Mini Tailless Excavator


Model

AZ 10

Engine type

Changchai192/KOOP 192

Bucket capacity

0.025 cubic meter

Power

12 horsepower

Working device form

backhoe

back turning radius

1190mm

Track total length

1235mm

Digging height

2490mm

Platform ground clearance

380mm

Discharge height

1750mm

Chassis width

930mm

Ground digging radius

2400mm

Track width

180mm

Vertical digging depth

1320mm

Track height

320mm

Upgrade height of bulldozer blade

325mm

transportation length

2550mm

Operating Weight

900kg

Whole vehicle height

1330mm-2195mm

Digging depth

1400mm

Multi-way valve

KDK(Italy)

Walking motor

Eaton(USA)

Rotary Motor

Eaton/Lucheng

Hydraulic pump

KDK


AZ12 Mini Tailless Excavator



Model

AZ 12

Engine type

Koop double-cylinder oil cooling

Bucket capacity

0.025 cubic meter

Power

12 horsepower

Working device form

backhoe

back turning radius

1190mm

Track total length

1235mm

Digging height

2490mm

Platform ground clearance

380mm

Discharge height

1750mm

Chassis width

946mm

Ground digging radius

2400mm

Track width

180mm

Vertical digging depth

1320mm

Track height

320mm

Upgrade height of bulldozer blade

325mm

transportation length

2550mm

Operating Weight

1060kg

Whole vehicle height

2195mm

Digging depth

1400mm

Multi-way valve

KDK(Italy)

Walking motor

Eaton(USA)

Rotary Motor

Eaton/Lucheng

Hydraulic pump

Hengsheng


AZ16 Mini Tailless Excavator



Engine model Yanmar 3TNV7
Rated power 10kw/2200/r/min
Swing motor USA Eaton
Traveling motor Korea DONGHYUN
Overall dimension( LxWxH) 3160x1040x2377 mm
Chassis width 1040mm
Track width 180mm
Max. Dumping height 2310mm
Delivery time 15 days
Loading 12 units in 40HC
Product Keywords buckets for excavators,360 excavators for sale

AZ20 Mini Tailless Excavator


Model

AZ20

Engine model

YANMAR 370 Water cooled

Bucket capacity

0.045m3

Power

13.6hp

Working device form

Backhoe

Radius of gyration

1440mm

Track length

1450mm

Excavation height

3275mm

Platform ground clearance

435mm

Unloading height

2310mm

Chassis width

1130mm

Ground excavation radius

2470mm

Track width

230mm

Vertical excavation depth

1740mm

Track Height

320mm

Bulldozer lift height

262mm

Transport length

3160mm

Weight

1600kg

Vehicle height

2377mm

Excavation depth

2150mm

Multi way valve

North Heavy Industry

Walking motor

Eaton (American)

Rotary motor

Eaton (American)

Hydraulic pump

KDA (Italy)


AZ9 Mini Tailless Excavator

Total weight
8770kg
Bucket capacity
0.3m3
Engine power/pm
33.7 kw/2100 rpm
Wheel travelling speed
25 km/h
Track travelling speed
2. 3km/h
Swing speed
9pm
Max. grade ability
30°
Hydraulic system
Rexroth from Germany
Pump
variable capacity pump
Pressure
25 Mpa
Displacement
132 L/min
Capacity of hydraulic tank
175L
Capacity of fuel tank
150L
Engine oil capacity
12L
Max. digging radius
6880mm
Max. digging radius (on ground)
6735mm
Max. digging depth
3772mm
Max. dumping height
5220mm
Min. turning radius
26 I 7mm
Bucket digging force (KN)
56KN
Bucket am digging force (KN)
36KN
